VAP-A40UO
1-1/2" Double Diaphragm Pump
(Aluminum Alloy Pump)


● Liquid Inlet: 1-1/2" PT(BSP)
● Air Inlet & Outlet: 1/2" PT(BSP) & 1" PT(BSP)
● Diaphragm: UPE
● Wetted & Center Body: Aluminum
● Pipe Type: Center
● Ball Cover: Aluminum
● Ball: PTFE
● Ball Seat: Stainless Steel
● Certificates: CE/ Ex II 2 GD c IIB T4~T5

VAP-A40UO
1-1/2" Double Diaphragm Pump
(Aluminum Alloy Pump)


● Dimension: (L)39 x (W)29 x (H)46 cm
● Min. Pressure: 1.2 Bar(kgf/cm2); 17.4 psi
● Max. Pressure: 8.0 Bar(kgf/cm2); 116 psi
● Working Pressure Advised: 1.5-3.5 Bar(kgf/cm2); 21.75-50.76 psi
● Quantity/ Cycle: 1.45 L
● Air Cons.: 2300 L/min (81.22 SCFM)
● Solid Limit: Ø4.5 mm
● Inlet Lift (Deep): 6 m-Wet / 3.7 m-Dry
● Max Flow Rate: 81.89 GPM (310 LPM)
● Weight: 18 kg
