1/4" Aluminum Air Screwdriver
1/4" Aluminum Air Screwdriver
● Front Exhaust
● Free Speed: 9,000 RPM
● Working Torque (5 sec): 136 Nm (100 ft-lb)
● Two Hammer Mechanism
● Vibration: 5.1 m/s2
● Sound Pressure: 97 dBA
1/4" Aluminum Air Screwdriver
|
Model No. |
Hex |
Working |
Free |
Bolt |
Net |
Overall |
Air |
Air Inlet |
Hose |
||||||
|
六角尺寸 |
工作扭力 |
無負載轉速 |
螺栓能力 |
重量 |
長度 |
耗氣量 |
進氣口 |
氣管 |
|||||||
|
mm |
ft-lb |
N-m |
R.P.M |
Inch |
mm |
lb |
kg |
Inch |
mm |
CFM |
l/min |
NPT(PT) |
Inch |
mm |
|
|
SA6426 |
1/4 |
100 |
136 |
9,000 |
15/64 - 5/16 |
6 - 8 |
2.20 |
1.00 |
7.95 |
202 |
4.0 |
113 |
1/4" |
3/8 |
10 |
