VAP-S31UO         UPE Diaphragm
VAP-S31TO          PTFE Diaphragm
1" Double Diaphragm Pump
(Stainless Steel Pump)


● Liquid Inlet & Outlet: 1" NPT
● Air Inlet & Outlet: 3/8" NPT
● Wetted & Center Body: SUS316 & Aluminum
● Pipe Type: Center
● Valve Seat: SUS304
● Ball Cover: Stainless Steel
● Ball: PTFE
● Ball Seat: Stainless Steel
● Certificates: CE/ Ex II 2 GD c IIB T4~T5

VAP-S31UO         UPE Diaphragm
VAP-S31TO         PTFE Diaphragm
1" Double Diaphragm Pump
(Stainless Steel Pump)


● Dimension: (L)29 x (W)26 x (H)39 cm
● Min. Pressure: 0.5 Bar(kgf/cm2); 7.25 psi
● Max. Pressure: 8.3 Bar(kgf/cm2); 120 psi
● Working Pressure Advised: 1.5~5 Bar(kgf/cm2); 21.75~72.5 psi
● Quantity/ Cycle: 450 ml
● Solid Limit: Φ3.0 mm
● Air Cons.: 1200 L/min (42.36 SCFM)
● Inlet Lift (Deep): 6 m-Wet / 3.7 m-Dry
● Max Flow Rate: 47.49 GPM (180 LPM)
● Weight: 14 kg
